Frame
FACT 11m carbon chassis, rear-end and link, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
-
Seat Binder
Alloy, 38.6mm
-
SWAT
SWAT 4.0 internal downtube storage
-
Rear Shock
FOX FLOAT X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSC adjustment, LSR adjustment, 210x55mm
-
Fork
FOX FLOAT 36 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm Kabolt axle, 44mm offset, S1:150mm of travel, S2-S6:160mm of travel
-
Front Brake
Shimano XTR, 4-piston caliper, hydraulic disc
-
Rear Brake
Shimano XTR, 4-piston caliper, hydraulic disc
-
Shift Levers
Shimano XTR Di2
-
Rear Derailleur
Shimano XTR Di2, 12-speed
-
Cassette
Shimano XTR, 12 Speed, 10-51T
-
Chain
Shimano XTR, 12-speed w/ quick link
-
Crankset
Shimano XTR, 55mm chainline, 32T, S1-S3: 165mm, S4-S6: 170mm
-
Bottom Bracket
Shimano BB93
-
Front Tire
Butcher, GRID TRAIL casing, Gripton T9 compound, 29X2.4
-
Front Wheel
Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra Hub, 15x110mm, 28h, DT Swiss Revolite Spokes
-
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
-
Rear Wheel
Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra Hub, 12x148mm, 28h, DT Swiss Revolite Spokes
-
Inner Tubes
Standard, Presta Valve
-
Stem
Race Face Turbine R, 35mm clamp, 40mm length
-
Handlebars
RaceFace ERA Carbon, 5-degree upsweep, 8-degree backsweep. S1-S2: 800 width, 20mm rise: S3-S6: 800 width, 55mm rise
-
Grips
Deity Lockjaw Grips
-
Saddle
Specialized S-Works Power Mirror, Ti Rails, S1-S2: 155mm, S3-S6:143mm
-
SeatPost
FOX Transfer NEO Factory, 34.9, S1:125mm, S2: 150mm, S3: 175mm, S4-S6: 200mm
-
Product ID
291508
-
Weight
13.95 kg (30 lb, 12.1 oz)
-
Weight Size
S4
