Frame:
-
FACT 10m carbon, 29" geometry, FACT IS construction, tapered headtube, carbon PF30 BB, full internal shift/brake routing, 142+ dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger
-
Fork:
-
Custom RockShox SID 29 Brain, inertia valve damper, Solo Air spring, tapered alloy steerer, top-mount Brain Fade and rebound adj., 15mm thru-axle, S: 80mm, Others: 90mm travel
-
Front Derailleur:
-
SRAM X0, 10-speed, 34.9mm clamp, dual-pull
-
Rear Derailleur:
-
SRAM X0 Type 2, 10-speed, mid cage
-
Number of Gears:
-
20
-
Shifters:
-
SRAM X0, 10-speed, trigger
-
Chainset:
-
Custom SRAM carbon S-2200, 10-speed XC double, PF30 spindle, removable spider, S: 170mm, Others: 175mm
-
Chainrings:
-
38/24T
-
Bottom Bracket:
-
SRAM PF30, OS press-in bearings, sealed cartridge
-
Cassette:
-
SRAM PG-1050, 10-speed, 11-36
-
Chain:
-
SRAM PC 1051, 10-speed, PowerLink
-
Pedals:
-
Resin Test Ride
-
Front Brake:
-
Magura MT6, hydraulic disc, Hi Friction pad, alloy calliper, Storm SL rotor, S/M: 160mm rotor, L/KL: 180mm
-
Rear Brake:
-
Magura MT6, hydraulic disc, Hi Friction pad, alloy calliper, Storm SL rotor, 160mm rotor
-
Brake Levers:
-
Magura MT6, carbon master cylinder, alloy lever blade, hollow lever pivot, reach adj., Shiftmix clamps
-
Handlebars:
-
S-Works XC, flat bar, carbon, 700mm wide, 8-degree backsweep, 31.8mm
-
Stem:
-
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
-
Headset:
-
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
-
Grips:
-
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: Regular, Others: XL thickness
-
Rims:
-
Roval Control Carbon 29, carbon disc, hookless bead, 22mm internal width, 32h
-
Front Hub:
-
Roval Control Carbon 29, 15mm thru-axle, 32h
-
Rear Hub:
-
Roval Control Carbon 29 142+, DT Swiss Star Ratchet, 12mm thru-axle, 32h
-
Spokes:
-
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
-
Front Tyre:
-
S-Works Fast Trak, 2Bliss Ready, 29×2.0″, foldable aramid bead, 120 TPI
-
Rear Tyre:
-
Specialized Fast Trak Control, 2Bliss Ready, 29×2.0″, foldable aramid bead, 60 TPI
-
Tubes:
-
Ultralight PV
-
Saddle:
-
Body Geometry Phenom Expert, hollow Ti rails, 143mm
-
Seatpost:
-
Specialized 2014 butted alloy, single bolt setback, 27.2mm, S/M: 350mm, L/XL: 400mm
-
Seat Binder:
-
Specialized 7050 hard anodised alloy, single bolt, 31.8mm
-
SWAT:
-
Bottle cage, EMT Tool, and Top Cap Chain Tool w/ SWAT Technology
-
Weight:
-
Not Specified
