Frame
Alloy chassis and rear-end, asymmetrical design, 29 Trail Geometry, horst pivot BB adjustment, threaded BB, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
Fork
FOX FLOAT 34 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 140mm of travel
Rear Shock
FOX FLOAT DPS Performance, Rx Trail Tune, rebound and 3-position compression adjust, S1:190x42.5mm, S2-S6: 190x45mm
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
Seatpost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Seat Clamp
Alloy, 38.6mm
Rear Brake
SRAM G2 R, 4-piston caliper, hydraulic disc, 180mm
Front Brake
SRAM G2 R, 4-piston caliper, hydraulic disc, 200mm
Chainrings
32T
Shift Levers
SRAM NX Eagle, trigger, 12-speed
Crankset
SRAM NX Eagle, DUB, S1:165mm, S2-S5: 170mm, S6: 175mm
Rear Derailleur
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Chain
SRAM NX Eagle, 12-speed
Rear Tire
Purgatory, GRID casing, GRIPTON? T7 compound, 29x2.3
Front Tire
Butcher, GRID casing, GRIPTON? T7 compound, 29x2.3
Inner Tubes
Standard, Presta valve
